Circular log saw Blue Bird: for cutting firewood with a cradle support

The circular log saw Blue Bird 170 mm is designed to make preparing firewood easier with an electric cutting assembly. The stated capacity of 170 mm identifies the variant’s cutting size, which is distinct from the blade diameter.

Blade and power supply

The 3000 W motor uses a 230 V 50 Hz power supply. The blade has a 505 mm diameter and 30 mm bore, with a speed of 2800 rpm. The manufacturer specifies an IP54 rating; installation and operating conditions must still comply with the manual.

Use and maintenance

Follow the manual for supporting and feeding firewood and using the guards. Disconnect the machine before working on the blade or fasteners.

Technical specifications

• Brand: Blue Bird
• Model / reference: 170 mm
• Product code: 888410
• EAN: 8025518494716
• Power supply: 230 V 50 Hz
• Power: 3000 W
• Blade diameter/bore: 505 / 30 mm
• Cutting capacity: 170 mm
• Blade speed: 2800 rpm
• Protection rating: IP54
• Stated weight: 56.3 kg

Included equipment

• Machine: Circular log saw 170 mm with cutting assembly
