Tractor log splitter Blue Bird LS PTO 30000: for preparing firewood

The tractor log splitter Blue Bird LS PTO 30000 is designed to make firewood preparation easier by splitting logs with a stated mechanical force of 30 tonnes. This configuration is powered by the tractor’s PTO.

Log dimensions and configuration

The model’s specification table lists a splitting length of 1100 mm and a diameter of 400 mm. These dimensions help you choose the machine for the logs to be prepared, together with the conditions permitted by the manual. The stated splitting force does not represent hourly output or a guarantee that every wood species can be processed under the same conditions.

Connecting to the tractor

Check PTO compatibility, connection and guards before use. The tractor is a separate machine; check whether the PTO drive shaft is included before purchasing.

Use and maintenance

Follow the manual for positioning logs and using the controls. Stop the machine and disconnect its power source before maintenance. Check the system’s connections and guards.

Technical specifications

• Brand: Blue Bird
• Model / reference: LS PTO 30000
• Product code: 884350
• EAN: 8025518410020
• Power source / engine: Tractor PTO via drive shaft
• Stated splitting force: 30 t
• Splitting length: 1100 mm
• Splitting diameter: 400 mm
• Stated weight: 346 kg

Included equipment

• Machine: Tractor log splitter LS PTO 30000
